Maximum cutting performance under full load | Eberle nanoflex® VTX coated

The following application case clearly shows how crucial it is to select a high-performance saw band with the appropriate technical parameters to achieve process stability and maximum cutting performance.

MATERIAL:
1.7225 / 42CrMo4 / AISI 4140
(hardenable CrMo steel)
Dimension 1200 × 650 mm

👉 USE:
nanoflex® VTX coated - 80 x 1.6 mm 0.75 / 1.25 TPI

CUTTING PARAMETERS:
• cutting speed Vc = 27–30 m/min
• feed rate Vf = 3.6–4.2 mm/min

RESULT:
• high cutting performance under full load
• process-reliable operation
• reduced cost per cut

ADVANTAGES IN USE:
• high performance with large cutting lengths
• reduced cutting forces through optimized tooth geometry
• improved heat dissipation and chip formation
• long service life thanks to TiAlN coating

The specially designed band geometry of the VTX technology shows its strengths especially with large to very large cutting lengths, even with hardenable steels.

KEY ADVANTAGE:
Powerful machining in the bimetal sector - without the use of carbide band saws.
